S34U18 meter series is a solution for industrial,commercial and residential customers.It
has strong functionality,.and provides interoperablity and external communication technology.
The solution can act asa gateway for collecting data from gas,heat and water meters. It has
various user interface, anti-tampering function, high secure encryption technology, etc. Flexible
and modular design can meet today's rapidly changing markets
- Active, reactive and apparent energy measurement
- Accuracy up to Cl.1/CI.B (MID) [active energy] and Cl.2 [reactive energy
- Wide range measurement from starting current to maximum current
- Up to 8 tariffs
- Button for display control, Button with sealing for manual billing.
- Optical & RS485 & Mbus & P1 interface
- Ultility meter read (read consumption from gas,water and heat meters)
- Loadprofile/billing/event record
- FW upgrade for meter and module
- High secure communication suite 0/1
- Interchangable modules
- Anti-Tampering for strong magnetic/abnormal wiring/cover removed, etc.
- Installation standard according to DIN 43857
- Polycarbonate with glass fibre, flame retardant and heat-proof
|Current||Range||5 ( 60 ) A
5 ( 80 ) A
5 ( 100 ) A
|Remote communication type||4G/3G/2G/PLC/RF|
